Bracket
| Nummer: | Bestelnummer: | OEM: | Omschrijving: |
| 1 | PAGB/T889.1-M8 | 3V1-61324-0 | NUT M8 |
| 2 | PAF8-00000100 | 895167001 | ABSORBER(FRONT) |
| 3 | PAGB/T5783-M6X20 | 97095-06020 | BOLT M6X20 |
| 4 | PAGB/T97.1-6 | 92990-06600-00 | WASHER 6 |
| 5 | PAF8-02000100 | 853771004 | ABSORBER ASSY |
| 6 | PAF8-01000003 | 16-895166002, | DICEPHALOUS BOLT M8X65 |
| 7 | PAF8-01020000 | STEER BRACKET ASSY | |
| 8 | PAF8-01010200 | 369-62122-2 | THRUST ROD ASSY |
| 9 | PAF4-01050002 | 90502-08M05 | CONICAL SPRING |
| 10 | PAF4-01020000 | 6E0-43112-01-4D | BRACKET ASSY(LEFT) |
| 11 | PAF4-01000002 | 6E0-43112-01-4D | PLATE, TWO HOLE |
| 12 | PAGB/T889.1-M8 | 3V1-61324-0 | NUT M8 |
| 13 | PAGB/T6170-M6 | NUT M6 | |
| 14 | PAF4-01010004 | 6L8-G3118-01 | CLAMP HANDLE,STERN |
| 15 | PAF4-01010005 | 90243-04M01 | RIVET, CLAMP HANDLE |
| 16 | PAF4-01010002 | 6E7-43116-00-00 | CLAMP SCREW |
| 17 | PAF4-01010003 | 620-43114-00 | CLAMP PAD |
| 18 | PAF4-01000003 | 803772T01 | WASHER, NYLON |
| 19 | PAF8-01010101 | ROTARY BRACKET | |
| 20 | PAF8-01000001 | 8037741 | WASHER, ROTARY BRACKET |
| 21 | PAF8-01000002 | 350-62417-0 | BUSHING, ROTARY BRACKET |
| 22 | PAF8-01000100 | 345-62441-0 | LOCKING BLOCK ASSY |
| 23 | PAF8-01010102 | 346-62421-1 | SPRING, LOCKING |
| 24 | PAGB/T5783-M8X30 | 910113-0830 | BOLT M8X30 |
| 25 | PAF4-01010000 | 6E0-43111-01-4D | BRACKET ASSY(RIGHT) |
| 26 | PAGB/T5782-M8X140 | BOLT M8X140 | |
| 27 | PAGB/T5782-M6X130 | 90101-06M18-00 | BOLT M6X130 |
| 28 | PAF8-01010001 | TUBE, BOLT | |
| 29 | PAJB/T7940.1-M6 | 344-67177-0 | OILER M6 |
| 30 | PAJASO F404 35-022 | 8126412 | O-RING (22.4X) 3.5 |
| 31 | PAF8-01010108 | 3B2-66321-1 | SHAFT, ROTARY BRACKET |
| 32 | PAGB/T896-5 | 945303-0500 | CIRCLIP 5 |
| 33 | PAF8-00000002 | 803775006, | ABSORBER |
| 34 | PAT15-02010100 | TIGHTWIRE B | |
| 35 | PAGB/T5782-M6X75 | BOLT M6X75 | |
| 36 | PAF8-00000001 | 803776004 | SHELL, ABSORBER |
| 37 | PAF8-01010106 | 3V1-66313-0 | OUTER FRAME, ROTARY BRACKET |
| 38 | PAF8-01010112 | 350-62121-1 | TIE-IN, CONNECTING ROD |
| 39 | PAF8-01010110 | CONNECTING ROD, INNER FRAME | |
| 40 | PAF8-01010111 | TIE-IN, CONNECTING ROD | |
| 41 | PAF8-01010107 | INNER FRAME, ROTARY BRACKET | |
| 42 | PAF8-01010109 | 3B2-66315-0 | SPRING,WREST |
| 43 | PAF8-01010104 | 369-66112-1 | SPRING,SUPPORT |
| 44 | PAF8-01010103 | 393-62437-0 | BUSRING |
| 45 | PAF8-01010105 | 369-62439-1 | PRESS PLATE |
| 46 | PAGB/T5783-M6X12 | BOLT M6X12 | |
| 47 | PAF8-01010300 | 815094A04 | SUPPORT ASSY |
| 48 | PAF4-01030103 | 6E0-43632-00 | HANDLE COVER |
-
Parsun Rohr Bolzen (PAF8-01010001)16,67 € 14,01 €
